Product Parameters：
Product Model | AM1~6UX |
Material | Hydrophobic acrylic |
Optic Diameter | 6.0 mm |
Overall Length | 13.0 mm |
Theoretical A Constant | 118.2 |
| Optimized Constants | Ultrasound biometry A=118.8 Optical biometry A=119.2 SRK/T A=119.2 SRK II A=119.6 Haigis a0=1.50, a1=0.40, a2=0.10 Hoffer Q pACD=5.69 Holladay sf=1.95 Holladay II ACD=5.69 Barrett LF=2.0, DF=2.5 |
Opticaldesign | Anterior toric surface, posterior high order aspheric surface |
Haptic Design and Angulation | Modified “L”loop, 1.5° |
Light filtering | UVfiltering |
Optic Power Range | Spherical power:+5.0D~+36.0D , 0.5D increments Cylinder power: 1.00D, 1.50D, 2.25D, 3.00D, 4.00D, 4.50D |
